| 型号 | 冲程 (mm) | 总长度 (mm) | 杆直径 (mm) | 筒外径 (mm) | 阻尼力（N） 100mm/s | 电流 (A) | 电阻 (Ω) | 底部安装孔 | 头部安装孔 | 气室气压 (MPa) |
| C30-40B01 | 40±2 | 225 | 10 | 30 | 60-210±15% | 0-1.5 | 1 | Φ8 | Φ8 | 0.6 |
| C30-50B01 | 50±2 | 255 | 10 | 30 | 60-210±15% | 0-1.5 | 1 | Φ8 | Φ8 | 0.6 |
| C38-60A01 | 60±5 | 460 | 14 | 38 | 150-600±15% | 0-3 | 1.5 | Φ12 | / | 0.63 |
| C38-60B01 | 60±5 | 460 | 14 | 38 | 230-850±15% | 0-3 | 1.5 | Φ12 | / | 0.63 |
| C38-60C01 | 60±5 | 460 | 14 | 38 | 270-1050±15% | 0-3 | 1.5 | Φ12 | / | 0.63 |
| C39-40B01 | 40±3 | 240 | 10 | 39 | 220-1350±15% | 0-1.5 | 4.5 | Φ12 | Φ12 | 2.0 |
| C45-55A01 | 55±5 | 295 | 10 | 45 | 145-1500±10% | 0-1.5 | 5 | Φ12 | Φ12 | 2.0 |
| C45-55B01 | 55±5 | 295 | 10 | 45 | 270-2250±10% | 0-1.5 | 5 | Φ12 | Φ12 | 2.0 |
| C45-55C01 | 55±5 | 295 | 10 | 45 | 380-3000±10% | 0-1.5 | 5 | Φ12 | Φ12 | 2.0 |
| C50-175A01 | 175±10 | 620 | 14 | 50 | 220-2100±10% | 0-3 | 1.5 | Φ12 | Φ12 | 2.0 |
| C50-175B01 | 175±10 | 620 | 14 | 50 | 350-2900±10% | 0-3 | 1.5 | Φ12 | Φ12 | 2.0 |
| C50-175C01 | 175±10 | 620 | 14 | 50 | 650-4200±10% | 0-3 | 1.5 | Φ12 | Φ12 | 2.0 |
| C50-155A01 | 155±10 | 620 | 14 | 50 | 270-2600±10% | 0-3 | 2.4 | Φ12 | Φ12 | 2.0 |
| C120-90B01 | 90±5 | 755±5 | 30 | 120 | 1000-20000±15% | 0-2.5 | 13 | Φ40 | Φ40 | 2.0 |
